Special Roll
| Type | Design | Surface | Features |
|---|---|---|---|
| Coating Roll |  |
hard chrome plated or rubber coated | minimized deflection thanks to internal axis and two interior bearings |
| Rubber-Roll |  |
rubber coated, alternatively including Teflon-sleeve | low cooling efficiency, good stiffness |
| Stretch Roll |  |
hard chrome plated, nickel-plated, finish-polished or matt | very good cooling efficiency, good stiffness despite of small diameter low pressure design |
| Embossing roll |  |
leather, prism, hygienic, sand, skyto, chessboard, orange peal a.m.o. | good cooling efficiency, good stiffness |
| Calander Roll, double shell |
 |
hard chrome plated, finish-polished | good cooling efficiency, good stiffness |
| Calander Roll, single shell |
 |
hard chrome plated, finish-polished | low cooling efficiency |
| Godet Roll |  |
hard chrome plated, finish-polished or ceramic coated | good cooling efficiency bearing support on one side only to enable better accessibility |
×
![]()
Special designs
Type
Coating RollSurface
hard chrome plated or rubber coatedFeatures
minimized deflection thanks to internal axis and two interior bearingsType
Rubber-RollSurface
rubber coated, alternatively including Teflon-sleeveFeatures
low cooling efficiency, good stiffness
Type
Stretch RollSurface
hard chrome plated, nickel-plated, finish-polished or mattFeatures
very good cooling efficiency, good stiffness despite of small diameter low pressure designType
Embossing rollSurface
leather, prism, hygienic, sand, skyto, chessboard, orange peal a.m.o.Features
good cooling efficiency, good stiffness
Type
Calander Roll, double shellSurface
hard chrome plated, finish-polishedFeatures
good cooling efficiency, good stiffnessType
Calander Roll, single shellSurface
hard chrome plated, finish-polishedFeatures
low cooling efficiency
